Product Overview
Kee Clamp Galvanised Railing in Saudi Arabia
- Kee Clamp Galvanised Railing is a modular safety railing and handrail system designed for industrial safety applications.
- Kee Clamp systems provide weldless edge protection and access control using slip-on tubular guardrail components.
- Clamp fittings are mechanically fixed to galvanised steel pipes with case-hardened set screws to hold them firmly and maintain a straight railing line.
- The system can be used on rooftops, mezzanines, stair landings, walkways, platforms, machinery areas, and other locations where safety boundaries are required.
- Kee Clamp Galvanised Railing is easy to install, adjust, and extend in the future when site requirements change.
- The galvanised finish provides corrosion protection and long service life in harsh indoor and outdoor conditions.
- Optional toe boards, infill panels, safety gates, and powder coating can be added depending on project requirements.
Performance Standards & Compliance
The kee clamp galvanised railing system meets international safety standards:
Kee Clamp Galvanised Railing Requirements in Saudi Arabia
The Kee Clamp Galvanised Railing system is a modular system of galvanised handrails and guardrails used in industrial and rooftop safety applications. It uses galvanised malleable cast iron fittings with galvanised steel pipe to support edge protection, controlled access, and safer movement in workplace environments.
-
OSHAOSHA 1910.29 / 1926.502Serves guardrail and fall protection needs for industrial and construction use.
-
Building CodeIBCSupports building safety, access, and guardrail design considerations where appropriate.
-
Cast IronASTM A47Provides malleable cast iron material specifications to support fitting strength and quality.
-
Steel PipeASTM A53 / ASTM A500Supports galvanised steel pipe and tube compatibility for railing systems.
-
GalvanizingASTM A123 / ASTM A153Offers hot-dip galvanizing specifications for corrosion resistance and durability.
-
ISOBS EN ISO 1461Supports hot-dip galvanizing standards for galvanised cast iron components.
-
Tested DataTÜV-Tested Connector DataSupports tested connection performance and manufacturing quality of railing fittings.
Technical Specifications
| Product / System | Kee Clamp Galvanised Railing Modular safety railing and handrail system |
| System Type | Slip-On Tubular Guardrail For industrial and rooftop safety applications |
| Main Material | Galvanised Malleable Cast Iron Used with galvanised steel pipe |
| Pipe Size | 42 mm OD Standardized pipe diameter |
| Pipe Standard | ASTM A53 / ASTM A500 Compatible Suitable for galvanised steel pipe or tube |
| Surface Finish | Hot-Dip Galvanised Optional powder coating available |
| Joint Method | Mechanical Slip-On Fittings Locked with case-hardened set screws |
| Set Screw Torque | 39 Nm Recommended tightening torque |
| Safety Factor | Minimum 2:1 Supports reliable system performance |
| Railing Geometry | 42 in Top Rail / 21 in Mid Rail Toe board where required |
| Post Spacing | 72 in / 1829 mm Maximum Recommended maximum post spacing |
| Compliance | OSHA, IBC, ASTM, TÜV Data Based on approved project configuration |
How Kee Clamp Galvanised Railing Works for Safety?
The Kee Clamp Galvanised Railing system works by connecting galvanised steel pipes with mechanical Kee Clamp fittings. Each fitting slips over the pipe and is clamped with set screws to form a strong handrail or guardrail without welding, threading, or hot work.
- Kee Clamp fittings are designed to be assembled quickly on-site using standardized modular components.
- The top rail, mid rail, upright posts, and returns are made from galvanised steel pipes.
- Kee Clamp fittings are connected at each joint to keep the railing properly aligned and firmly secured.
- The system supports edge protection around rooftops, platforms, mezzanines, walkways, and other safety areas.
- Modular components can be adjusted, extended, repaired, or replaced easily when site requirements change.
Durable Kee Clamp Galvanised Railing for Industrial Safety
Kee Clamp Galvanised Railing offers a high-quality modular safety railing system for industrial, commercial, and rooftop applications. The system is designed using galvanised steel pipe and Kee Clamp fittings to form strong, corrosion-resistant handrail protection for access routes, elevated platforms, and work areas.
- Suitable for walkways, platforms, mezzanines, stair landings, rooftops, and machinery areas.
- Slip-on Kee Clamp components save installation time and do not require welding.
- Modular handrail layouts can be designed according to site size and access requirements.
- Galvanised parts help resist corrosion and support long service life in demanding environments.
Secure Your Site with Kee Clamp Galvanised Railing Today
Get a quote - Kee Clamp Galvanised Railing and Handrail Systems in Saudi Arabia
Improve workplace safety with durable Kee Clamp Galvanised Railing, modular Key Clamp fittings, and reliable Handrail systems to rooftops, platforms, walkways, stairways, and industrial access areas.
